Subagent Streaming

Display specialist subagents with streaming content, progress tracking, and collapsible cards

When a coordinator agent spawns specialist subagents — a researcher, an analyst, a writer — you need to render the orchestrator’s messages separately from each subagent’s streaming output. Set filterSubagentMessages: true in useStream to cleanly split these two streams, then use getSubagentsByMessage to attach each subagent’s progress card to the coordinator message that triggered it.

Why filter subagent messages

Without filtering, every token produced by every subagent appears interleaved in the coordinator’s message stream — making it unreadable. With filterSubagentMessages: true:

• stream.messages contains only the coordinator’s messages
• Each subagent’s content is accessible through stream.subagents and stream.getSubagentsByMessage
• The UI stays clean: the coordinator’s reasoning is separate from the specialists’ work

This separation lets you render the orchestrator’s messages in one place and attach each subagent’s progress card exactly where it belongs — beneath the coordinator message that spawned it.

Setting up useStream

Always set filterSubagentMessages: true. This removes subagent tokens from the main message stream so you can render the coordinator’s messages and subagent output independently.

Define a TypeScript interface matching your agent’s state schema and pass it as a type parameter to useStream for type-safe access to state values. In the examples below, replace typeof myAgent with your interface name:

import type { BaseMessage } from "@langchain/core/messages";

interface AgentState {
  messages: BaseMessage[];
}

React

import { useStream } from "@langchain/react";

const AGENT_URL = "http://localhost:2024";

export function DeepAgentChat() {
  const stream = useStream<typeof myAgent>({
    apiUrl: AGENT_URL,
    assistantId: "deep_agent_subagent_cards",
    filterSubagentMessages: true,
  });

  return (
    <div>
      {stream.messages.map((msg) => (
        <MessageWithSubagents
          key={msg.id}
          message={msg}
          subagents={stream.getSubagentsByMessage(msg.id)}
        />
      ))}
    </div>
  );
}

<script setup lang="ts">
import { useStream } from "@langchain/vue";

const AGENT_URL = "http://localhost:2024";

const stream = useStream<typeof myAgent>({
  apiUrl: AGENT_URL,
  assistantId: "deep_agent_subagent_cards",
  filterSubagentMessages: true,
});
</script>

<template>
  <div>
    <MessageWithSubagents
      v-for="msg in stream.messages.value"
      :key="msg.id"
      :message="msg"
      :subagents="stream.getSubagentsByMessage(msg.id)"
    />
  </div>
</template>

<script lang="ts">
  import { useStream } from "@langchain/svelte";

  const AGENT_URL = "http://localhost:2024";

  const { messages, getSubagentsByMessage, submit } = useStream<typeof myAgent>({
    apiUrl: AGENT_URL,
    assistantId: "deep_agent_subagent_cards",
    filterSubagentMessages: true,
  });
</script>

<div>
  {#each $messages as msg (msg.id)}
    <MessageWithSubagents
      message={msg}
      subagents={getSubagentsByMessage(msg.id)}
    />
  {/each}
</div>

import { Component } from "@angular/core";
import { useStream } from "@langchain/angular";

const AGENT_URL = "http://localhost:2024";

@Component({
  selector: "app-deep-agent-chat",
  template: `
    @for (msg of stream.messages(); track msg.id) {
      <app-message-with-subagents
        [message]="msg"
        [subagents]="stream.getSubagentsByMessage(msg.id)"
      />
    }
  `,
})
export class DeepAgentChatComponent {
  stream = useStream<typeof myAgent>({
    apiUrl: AGENT_URL,
    assistantId: "deep_agent_subagent_cards",
    filterSubagentMessages: true,
  });
}

Submitting with subgraph streaming

When submitting a message, enable subgraph streaming and set an appropriate recursion limit. Deep agent workflows often involve multiple layers of nested subagraphs, so a higher recursion limit prevents premature termination:

stream.submit(
  { messages: [{ type: "human", content: text }] },
  { streamSubgraphs: true }
);

DeepAgents sets a default recursion limit of 10,000, which is sufficient for most multi-expert setups. You can override this via config.recursion_limit if needed.

The SubagentStreamInterface

Each subagent exposes a SubagentStreamInterface with metadata about the subagent’s task, status, and timing:

interface SubagentStreamInterface {
  id: string;
  status: "pending" | "running" | "complete" | "error";
  messages: BaseMessage[];
  result: string | undefined;
  toolCall: {
    id: string;
    name: string;
    args: {
      description: string;
      subagent_type: string;
      [key: string]: unknown;
    };
  };
  startedAt: number | undefined;
  completedAt: number | undefined;
}

Property	Description
id	Unique identifier for this subagent instance
status	Lifecycle state: pending → running → complete or error
messages	The subagent’s own message stream, updated in real time
result	The final output text, available only when status is "complete"
toolCall	The tool call that spawned this subagent, including task metadata
toolCall.args.description	The task description the coordinator assigned to this subagent
toolCall.args.subagent_type	The type or name of the specialist (e.g., "researcher", "analyst")
startedAt	Timestamp when the subagent began executing
completedAt	Timestamp when the subagent finished

Linking subagents to messages

The getSubagentsByMessage method returns the subagents spawned by a specific AI message. This lets you render subagent cards directly beneath the coordinator message that triggered them:

const turnSubagents = stream.getSubagentsByMessage(msg.id);

This returns an array of SubagentStreamInterface objects. If the message didn’t spawn any subagents, it returns an empty array.

Building the SubagentCard

Each subagent card shows the specialist’s name, task description, streaming content or final result, and timing information:

import { AIMessage } from "@langchain/core/messages";

function SubagentCard({
  subagent,
}: {
  subagent: SubagentStreamInterface;
}) {
  const [expanded, setExpanded] = useState(true);

  const title =
    subagent.toolCall?.args?.subagent_type ?? `Agent ${subagent.id}`;
  const description = subagent.toolCall?.args?.description ?? "";

  const lastAIMessage = subagent.messages
    .filter(AIMessage.isInstance)
    .at(-1);

  const displayContent =
    subagent.status === "complete"
      ? subagent.result
      : typeof lastAIMessage?.content === "string"
        ? lastAIMessage.content
        : "";

  const elapsed = getElapsedTime(subagent.startedAt, subagent.completedAt);

  return (
    <div className="rounded-lg border bg-white shadow-sm">
      <button
        onClick={() => setExpanded(!expanded)}
        className="flex w-full items-center justify-between p-4"
      >
        <div className="flex items-center gap-3">
          <StatusIcon status={subagent.status} />
          <div>
            <h4 className="font-semibold capitalize">{title}</h4>
            <p className="text-xs text-gray-500">{description}</p>
          </div>
        </div>
        <div className="flex items-center gap-2">
          {elapsed && (
            <span className="text-xs text-gray-400">{elapsed}</span>
          )}
          <StatusBadge status={subagent.status} />
        </div>
      </button>

      {expanded && displayContent && (
        <div className="border-t px-4 py-3">
          <div className="prose prose-sm max-w-none line-clamp-6">
            {displayContent}
            {subagent.status === "running" && (
              <span className="inline-block h-4 w-1 animate-pulse bg-blue-500" />
            )}
          </div>
        </div>
      )}
    </div>
  );
}

function getElapsedTime(
  startedAt: number | undefined,
  completedAt: number | undefined
): string | null {
  if (!startedAt) return null;
  const end = completedAt ?? Date.now();
  const seconds = Math.round((end - startedAt) / 1000);
  if (seconds < 60) return `${seconds}s`;
  return `${Math.floor(seconds / 60)}m ${seconds % 60}s`;
}

Status icons and badges

Consistent visual indicators help users parse subagent status at a glance:

function StatusIcon({ status }: { status: SubagentStreamInterface["status"] }) {
  switch (status) {
    case "pending":
      return <span className="text-gray-400">○</span>;
    case "running":
      return <span className="animate-spin text-blue-500">◉</span>;
    case "complete":
      return <span className="text-green-500">✓</span>;
    case "error":
      return <span className="text-red-500">✕</span>;
  }
}

function StatusBadge({ status }: { status: SubagentStreamInterface["status"] }) {
  const styles = {
    pending: "bg-gray-100 text-gray-600",
    running: "bg-blue-100 text-blue-700",
    complete: "bg-green-100 text-green-700",
    error: "bg-red-100 text-red-700",
  };

  return (
    <span className={`rounded-full px-2 py-0.5 text-xs font-medium ${styles[status]}`}>
      {status}
    </span>
  );
}

Progress tracking

Show a progress bar and counter so users know how many subagents have finished:

function SubagentProgress({
  subagents,
}: {
  subagents: SubagentStreamInterface[];
}) {
  const completed = subagents.filter((s) => s.status === "complete").length;
  const total = subagents.length;
  const percentage = total > 0 ? Math.round((completed / total) * 100) : 0;

  return (
    <div className="space-y-1">
      <div className="flex items-center justify-between text-xs text-gray-500">
        <span>Subagent progress</span>
        <span>
          {completed}/{total} complete
        </span>
      </div>
      <div className="h-2 overflow-hidden rounded-full bg-gray-200">
        <div
          className="h-full rounded-full bg-blue-500 transition-all duration-300"
          style={{ width: `${percentage}%` }}
        />
      </div>
    </div>
  );
}

Rendering messages with subagent cards

The key layout pattern: render each coordinator message, and if that message spawned subagents, render their cards immediately below it:

function MessageWithSubagents({
  message,
  subagents,
}: {
  message: BaseMessage;
  subagents: SubagentStreamInterface[];
}) {
  if (message.type === "human") {
    return <HumanMessage content={message.content} />;
  }

  return (
    <div className="space-y-3">
      {message.content && (
        <div className="prose prose-sm max-w-none">
          {message.content}
        </div>
      )}

      {subagents.length > 0 && (
        <div className="ml-4 space-y-3 border-l-2 border-blue-200 pl-4">
          <SubagentProgress subagents={subagents} />
          {subagents.map((subagent) => (
            <SubagentCard key={subagent.id} subagent={subagent} />
          ))}
        </div>
      )}
    </div>
  );
}

Synthesis indicator

After all subagents complete, the coordinator takes time to synthesize their results into a final response. Show a clear indicator during this phase:

function SynthesisIndicator({
  subagents,
  isLoading,
}: {
  subagents: SubagentStreamInterface[];
  isLoading: boolean;
}) {
  const allComplete =
    subagents.length > 0 &&
    subagents.every((s) => s.status === "complete" || s.status === "error");

  if (!allComplete || !isLoading) return null;

  return (
    <div className="flex items-center gap-2 rounded-lg bg-purple-50 px-4 py-2 text-sm text-purple-700">
      <span className="animate-spin">⟳</span>
      Synthesizing results from {subagents.length} subagent
      {subagents.length !== 1 ? "s" : ""}...
    </div>
  );
}

The synthesis phase can take several seconds for complex multi-expert workflows. A clear “Synthesizing results…” indicator prevents users from thinking the agent has stalled.

Debug unfiltered output

During development, you can temporarily set filterSubagentMessages: false to see the raw, interleaved output from all subagents in the main message stream. This is useful for verifying that subagent tokens are flowing correctly, but should not be used in production UIs.

Use cases

Deep agent subagent cards are the right choice when your agent workflow involves:

• Deep research — a coordinator dispatches researchers to investigate different facets of a question, then synthesizes their findings
• Multi-expert analysis — domain specialists (legal, financial, technical) each contribute their perspective
• Complex task decomposition — a planner breaks a large task into subtasks and assigns each to a specialist worker
• Code review pipelines — separate agents handle security review, style checking, performance analysis, and documentation review

Accessing the full subagents map

Beyond per-message lookup, you can access all subagents at once through stream.subagents:

const allSubagents = [...stream.subagents.values()];
const running = allSubagents.filter((s) => s.status === "running");
const completed = allSubagents.filter((s) => s.status === "complete");
const errors = allSubagents.filter((s) => s.status === "error");

This is useful for building global progress indicators or dashboards that summarize all subagent activity regardless of which coordinator message spawned them.

Best practices

• Always set filterSubagentMessages: true. Unfiltered streams produce an unreadable interleaving of coordinator and subagent tokens.
• Show task descriptions — the toolCall.args.description field tells users exactly what each subagent was asked to do. Always display this prominently.
• Use collapsible cards — in workflows with 5+ subagents, auto-collapse completed cards so users can focus on active work.
• Display timing data — showing how long each subagent took helps users understand performance characteristics and identify bottlenecks.
• Set an appropriate recursion limit — deep agent workflows with nested subgraphs need higher limits than the default 25. Start with 100.
• Handle errors per subagent — one subagent failing shouldn’t crash the entire UI. Show the error in that subagent’s card while others continue running.

---
